BetaJBK dxing

I do all my dxing from or at my remote QTH, which is shown in the upper picture. It consists of:

- Elad FDM-S2 (in repair at Elad after a lightning damage)

- SDR Play RSP2 Pro under testing

- remotely operable antenna switch, Bonito Antenna Jet (in repair at Bonito after a lightning damage)

- Laptop with SDR-Radio.com Console and Server, SDR Uno, via virtual USB-ports Ergo4 + ILG and Rx_log_Tuner

- WLAN to router, 3G + DDNS to Web

- several clamp on cores everywhere, all equipment grounded to one point before out take to the antenna grounding point.

My city QTH is in the picture to the right

The antennas at the remote QTH:

- Triple-V-Beverage, total length 620 meters, 3 meters above ground level, grounding  with  1-2 kilo-ohm tunable carbon resistors, HFC- Nachrichtentechnik longwire balun to RG-58

- 40 meters long T2FD-antenna, center 8 meters high, sloping legs, omni-directional.

- everything grounded to 30 meters of 16 mm2 copper wire in the ground + five grounding rods to a level under  ground frost, two lightning arresters, antenna wires underground to house

Welcome to view some aspects of my dxing hobby in the picture carousels.

THANKS A LOT FOR THE QSL's  ! !

Conclution



SDR - The wheel reinvented. Manageability !
